8MP Dual-lens Dual-light Two-way Audio IP Camera

1/2.7" CMOS sensor

8MP wide-view resolution 4096 x 1944P (19:9)

180° wide-angle

Low illumination 0.01Lux

Day/Night, AWB/MWB, BLC, HLC, 2D/3D-DNR, Shutter, D-WDR, Mirror, Defogging

Multiply Style OSD Overlay, Motion Detection, Privacy Mask

RTSP and Onvif 17.06 compatible with many third-party NVR

H.264/H.265 dual-stream media server

Easy-to-use P2P Cloud service

Support user authentication, video data encryption

Support Alarm Snapshot to Email and FTP

Multiply WEB browser IE,Firefox 32bit ESR, Edge,Google Chrome,PC Client, Mobile APP remote access

RJ45 100mbps network port, IEEE802.3af PoE

Lightning protection 4000V

Strong water-proof housing, IP66

2 pcs Warm light + 3 pcs IR Array leds,IR distance:25-30M,

White light distance:25-30M,

Three light Modes: Mode 1: Smart Dual Light，Mode 2: Pure Infrared Light，Mode 3: Pure White Light

2*F1.6 2.8 mm fixed lens

Built-in Mic and speaker two-way audio

With SD card slot ,support UP to 512GB SD card

With reset button

Download PDF

Tech Specs

Details

Video

Model	YC-W738ADZ58A
Camera
Image Sensor	1/2.7" GC5623 CMOS x2
Effective Pixels	8 megapixels
Electronic Shutter	AUTO, 1/25s ~ 1/100000s
Min. Illumination	0.01Lux@F1.2(AGC ON)
Day/Night	Auto/Color/(B/W)/Timing
WDR	Digital WDR
White Balance	Auto/Manual
BLC /HLC	Support
DNR	2D/3D DNR
Other	Human body and Vehicle detection ,AGC,Motion Detection,Privacy Mask,Flip ,OSD overlay
Encode
Video Standard	H.264/H.265/H.265+
Video Resolution	MainStream:20fps@4096x1944P
Video Resolution	Sub stream: 20fps@1024x480
Video Bitrates	512Kbps - 8Mbps, VBR/CBR
Audio Standard	G.711-u/G.711-a/AAC
Built-in Mic	Yes
Built-in Speaker	Yes,Two-way audio
Smart Detection	Human body and Vehicle Detection
Led and distance
Led	2pcs warm-light Led + 3pcs IR Array Led
IR Distance	20-30 M
White light Distance	20-30 M
Lens
Focal length	2*F1.6 2.8 mm fixed lens
FOV	180°
Other FunctionS
With SD card slot ,support UP to 512GB SD card,with reset button
Network Services
Protocol	HTTP/RTSP/FTP/SMTP/DHCP/NTP/NFS, etc.
P2P	Yes
Web	IE , Firefox,Edge, Google Chrome etc.
Media	CMS, Android, IOS
ONVIF	17.06 compatible
General
Network Port	1-RJ45, 100Mbps, POE optional
Power Supply	12 VDC ± 10%
Power Consumption	< 10 W
Operating Temp.	-30℃-(+60)℃, 10%-90%RH

How does Network
IP Camera Work?

IP Camera connect directly to the network,with H.265 compressed technology to save the space and bandwidth. It can be remotely viewing in realtime and back up with high quality high definition 4K,5MP,2MP image or video with audio via any PC,Recorder and mobile app to secure people and world safe.

Features of ColorVu IP camera

Support multi-channel real-time face image comparison face matching deployment control and calibration linkage.
Deep Ai H.265 Smart ip camera with NVR can plug and play and checked by remote CMS and mobile app.
AI CMS can unified manage Multiple intelligent NVRs and remotely realtime view the people face.
