Home Product Network IP Camera N Series IP Camera Prime 8MP IPC (SSC338Q+IMX415)

4.5 Inch 8MP Perimeter Protection Auto Tracking Dual Light Two Way Audio 20X PTZ Camera with Wiper

1/2.8" Sony CMOS sensor

4K resolution 3840 x 2160P

Face Detection,Human&Vehicle Detection, Line Crossing, Area Entry/Leaving Detection, Area Intrusion Detection

Low illumination 0.01Lux

Day/Night (ICR), AWB, AGC, BLC, 2D/3D-DNR, IR-CUT

WDR, Motion Detection, Privacy Mask, Flip

RTSP and Onvif 23.12 Compatible

H.265/ H.264 Dual-stream Media Server

Easy-to-use P2P Cloud Service

Multi web browser, PC Client, Mobile APP, Remote access

RJ45 100mbps Network Port, IEEE802.3af PoE

Lightning Protection 4000V

Strong Water-proof Housing, IP66

8pcs Array IR LEDs, IR Distance 80-100 Meters

2pcs Warm Light LEDs, Light Distance 40-50 Meters

4.9~98mm 20X Optical Zoom Lens

Two Way Audio / Micro SD Slot (Up to 512G)

Support warm light on and colorful imaging when detect human body/vehicle

Support Audio Alarm to Warn Intruders off

Download PDF

Tech Specs

Details

Video

FAQ

Model	YC-N798FIRC-HS20X-HP4
Camera
Image Sensor	1/2.8" 8MP Sony IMX415 CMOS
Soc Chip	Sigmastar SSC378QE
Effective Pixels	3840(H)×2160 (V)
Exposure Shutter	AUTO/Manual: 1/10s ~ 1/8000s, Max. Shutter speed adjustable
Day/Night	Auto(Active/passive/schedule)/Day/Night, switch threshold, sensitivity
Image Adjust	Brightness,Saturation,Sharpness,Contrast,Denoise (0-100%) adjustable
White Balance	AWB/MWB
WDR	100db WDR
Light Mode	Smart(dual-light) / Infrared / White light, adjustable
Light Control	Auto/Manual, Brightness level (0-100%) adjustable
DNR	2D/3D DNR
Encode
Video Standard	H.264/H.265/MJPEG
Video Resolution	Main Stream:
	20fps@8MP(3840x2160)(default),30fps@6MP(3072x2048)/5MP(2592x1944)/4MP(2560x1440)/3MP(2304x1296)/1080P/720P
	Sub stream: 10fps@720P,30fps@D1(704x576)(default)/(720x480)/VGA(640x480)/QVGA(640x360)
	Third stream: 10fps@720P(default),30@D1(704x576)/(720x480)/VGA(640x480)/QVGA(640x360) -- (when third stream customized enabled, Face Detection and Perimeter protection will be disabled)
Video Bitrates	Main stream: 64kbps-8Mbps
	Sub/third stream: 64kbps-2048kbps
	VBR/CBR , quality(1-9), GOP(1-128)
Image Rotation	0 / 90 / 180 / 270 degree adjustable
Border Crop	X crop, Y crop
Image Mirror	horizon / vertical / horizon&vertical adjustable
OSD Overlay	Font size(1-4), position,Time, Title, AM/PM, Color, User OSD, Alarm OSD
Privacy Mask	4 areas
Region of Interest	ROI: Each stream support 8 areas
Audio Standard	G.711-u/G.711-a/AAC/PCM, AEC
Built-in Mic	Yes
Built-in Speaker	Yes
Led
Light	8pcs Array IR LEDs ,2pcs Warm light LEDs
Light Distance	IR: 80-100M, Warm light: 40-50M
Lens
Focal Length	4.9~98mm
IRIS	F1.6-F22
View Angle	56°(wide) ~ 3.86°(tele)
Zoom	20X Optical Zoom; Support Auto Tracking
PTZ
Pan/Tilt Range	Pan: 0° ~ 360°; Tilt: -15° ~ 90°
Preset Point	256
Control Speed	Pan: 0.5° ~ 100° /s; Tilt: 0.5° ~80° /s
A-B Scanning	Support
Auto Cruising	Support 1 groups patrol, Max. 32 presets in group
Power on Action	Preset/Scan/Cruise
Power-off Recovery	Support
Smart Tracking	Human Detection Tracking
Language
English, simplified Chinese, Chinese Traditional, Korean, etc.
Smart Detection
Motion Detection	Yes
Digital IO Alarm	1 pair Alarm-in/Alarm-out, normally open/normally close
Human & Vehicle Detection	support
Cross Line Detection	support
Perimeter protection	support
Face Detection	support
Target Detection Type	Human , vehicle, non-motor vehicle, Pet, Face (32px-800px)
Trigger Action Linkage	Snapshot, Record, Relay, White LED Flash, Voice siren
Trigger Action Linkage	Micro-SD, Email, FTP, NAS storage (optional)
Simultaneous Detection	Maximum 16 targets simultaneous detection
Storage Type	Schedule/Trigger: Micro-SD(512G) , Email, FTP, NAS
Network Services
Protocol	HTTP(s)/RTSP/FTP/SMTP/DHCP/NTP/DST/RTP/RTMP/P2P/HiK/IPv4/IPv6/NFS
P2P Mobile APP	Android, IOS
Web Access	IE, Firefox, Chrome, Edge, Safari, etc.
PC Tool	Windows, Mac
ONVIF	23.12 compatible (profile S G T M)
General
Network Port	1-RJ45, 100Mbps, PoE 48V in
Power Supply	12 VDC ± 10% 2A
Power Consumption	< 20 W
Operating Temp.	-30℃-(+60)℃, 10%-90%RH
Size	4 inch, 250245160mm
Weight	2 KG

4-inch AI Human Auto Tracking Dual-Light POE IP PTZ Camera

Human Detection, Vehicle Detection Cross Line, Enter Area, Leave Area, Intrusion, People Flow Counting, Crowd Density Monitoring

1. Can you provide OEM/ODM Service?

Sure, YCX has over 14-year experience in the security industry, which has the capability of offering excellent ODM/OEM services to customize security products. If you have your own design and have problems for production, welcome here! YCX can offer you stable quality and the best performance security products.
2. How about warranty?

All YCX products with 24 months warranty since the purchase date. During the warranty period, you can contact our tech support team anytime.
3. How long is the delivery time?

Usually 15 days after order be confirmed; sample within 7 days. But it will take a little longer if with heavy burden of production task. The final lead time is based on negotiation.Most orders will be shipped via door to door shipping services like DHL, UPS, FEDEX, TNT. While some bulk orders will be shipped via air shipping or sea shipping based on customer's required.Meanwhile, the tracking number will be provided once the goods were sent out.
4. What's the MOQ?

No MOQ required for sample order, at least one carton per model after sample order.
5. What's your main products?

YCX mainly provide POE IP security camera system including 3MP/5MP/8MP POE IP Cameras, PTZ cameras , WIFI camera and NVR, also 4 IN 1 cameras and DVRs. YCX developed own professional NVR software GUI 100%, which is stable and unique in the market, it could manage multi-brands IP cameras. Also all YCX IP cameras contain Hik private and standard OVF protocol, which can compatible very well with Hik NVR.
6. Are you a factory or trading company?

YCX Electronics founded in 2009,which is 100% real factory with covering 5000 square meters plant. with over 14 years experience in manufacture and export security CCTV Camera and recorder products. By using the advance ERP management system, experienced R&D team and strict quality control system,YCX can provide you with high quality security CCTV products.

How does Network
IP Camera Work?

IP Camera connect directly to the network,with H.265 compressed technology to save the space and bandwidth. It can be remotely viewing in realtime and back up with high quality high definition 4K,5MP,2MP image or video with audio via any PC,Recorder and mobile app to secure people and world safe.

Features of ColorVu IP camera

Support multi-channel real-time face image comparison face matching deployment control and calibration linkage.
Deep Ai H.265 Smart ip camera with NVR can plug and play and checked by remote CMS and mobile app.
AI CMS can unified manage Multiple intelligent NVRs and remotely realtime view the people face.
