1/2.8" CMOS Sensor
6MP HD Resolution Output
Face Detection,Human&Vehicle Detection, Line Crossing, Area Entry/Leaving Detection, Area Intrusion Detection.
Low illumination 0.01Lux
Day/ Night (ICR), AWR, 2D/3D-DNR, IR-CUT
WDR, Motion Detection, Privacy Mask, Flip
RTSP and Onvif 23.12 Compatible
H.265/ H.264 Dual-stream Media Server
Easy-to-use P2P Cloud Service
Multi web browser, PC Client, Mobile APP, Remote access
RJ45 100mbps Network Port, IEEE802.3af PoE
Lightning Protection 4000V
Strong Waterproof Housing IP66
8pcs Array IR LEDs, IR Distance 80-100 Meters
2pcs Warm Light LEDs, Light Distance 40-50 Meters
4.9~98mm Optical Zoom Lens
Two Way Audio / Micro SD Slot (Up to 512G)
Model | YC-N716FIRC-HS20X-HP4 |
Camera | |
Image Sensor | 1/2.8" Sony IMX335 CMOS |
Soc Chip | Sigmastar SSC377D |
Effective Pixels | 3072(H)×2048 (V) |
Exposure Shutter | AUTO/Manual: 1/10s ~ 1/8000s, Max. Shutter speed adjustable |
Day/Night | Auto(Active/passive/schedule)/Day/Night, switch threshold, sensitivity |
Image Adjust | Brightness,Saturation,Sharpness,Contrast,Denoise (0-100%) adjustable |
White Balance | AWB/MWB |
WDR | 100db WDR |
Light Mode | Smart(dual-light) / Pure Infrared / Pure White light, adjustable |
Light Control | Auto/Manual, Brightness level (0-100%) adjustable |
DNR | 2D/3D DNR |
Encode | |
Video Standard | H.264/H.265/MJPEG |
Video Resolution | Main Stream: |
25fps@6MP(3072x2048),30fps@5MP(2592x1944)/4MP(2560x1440)/3MP(2304x1296)/1080P/720P | |
Sub stream: 10fps@720P,30fps@D1(704x576)/(720x480)/VGA(640x480)/QVGA(640x360) | |
Video Bitrates | Sub stream: 64kbps-8Mbps |
Sub stream: 64kbps-2048kbps | |
VBR/CBR , quality(1-9), GOP(1-128) | |
Image Rotation | 0 / 90 / 180 / 270 degree adjustable |
Border Crop | X crop, Y crop |
Image Mirror | horizon / vertical / horizon&vertical adjustable |
OSD Overlay | Font size(1-4), position,Time, Title, AM/PM, Color, User OSD, Alarm OSD |
Privacy Mask | 4 areas |
Region of Interest | ROI: Each stream support 8 areas |
Audio Standard | G.711-u/G.711-a/AAC/PCM, AEC |
Built-in Mic | Yes |
Built-in Speaker | Yes |
Led | |
Light | 8pcs Array IR LEDs ,2pcs Warmlight LEDs |
Light Distance | IR: 80-100 M, Warm light: 40-50M |
Lens | |
Focal Length | 4.9~98mm |
IRIS | F1.6-F22 |
View Angle | 56°(wide) ~ 3.86°(tele) |
Zoom | 20X Optical Zoom; Support Auto Tracking |
PTZ | |
Pan/Tilt Range | Pan: 0° ~ 360°; Tilt: -15° ~ 90° |
Preset Point | 256 |
Control Speed | Pan: 0.5° ~ 100° /s; Tilt: 0.5° ~80° /s |
A-B Scanning | Support |
Auto Cruising | Support 1 groups patrol, Max. 32 presets in group |
Power on Action | Preset/Scan/Cruise |
Power-off Recovery | Support |
Smart Tracking | Human Detection Tracking |
Language | |
English, simplified Chinese, Chinese Traditional, Korean, etc. | |
Smart Detection | |
Motion Detection | Yes |
Digital IO Alarm | 1 pair Alarm-in/Alarm-out, normally open/normally close |
Human & Vehicle Detection | support |
Cross Line Detection | support |
Perimeter protection | support |
Face Detection | support |
Target Detection Type | Human Shape, vehicle, non-motor vehicle, Pet, Face (32px-800px) |
Trigger Action Linkage | Snapshot, Record, Relay, White LED Flash, Voice siren |
Micro-SD, Email, FTP, NAS storage (optional) | |
Simultaneous Detection | Maximum 16 targets simultaneous detection |
Storage Type | Schedule/Trigger: Micro-SD(512G) , Email, FTP, NAS |
Network Services | |
Protocol | HTTP(s)/RTSP/FTP/SMTP/DHCP/NTP/DST/RTP/RTMP/P2P/HiK/IPv4/IPv6/NFS |
P2P Mobile APP | Android, IOS |
Web Access | IE, Firefox, Chrome, Edge, Safari, etc. |
PC Tool | Windows, Mac |
ONVIF | 23.12 compatible (profile S G T M) |
General | |
Network Port | 1-RJ45, 100Mbps, PoE 48V in |
Power Supply | 12 VDC ± 10% 2A |
Power Consumption | < 20 W |
Operating Temp. | -30℃-(+60)℃, 10%-90%RH |
Size | 4 inch, 250*245*160mm |
Weight | 2 KG |
4-inch AI Human Auto Tracking Dual-Light POE IP PTZ Camera
