4.5-inch 8MP 20X Auto Tracking Dual-light IP PTZ Speed Dome Camera

1/2.8" Sony low-light CMOS sensor

4K 8MP resolution 3840 x 2160 output

low illumination 0.01Lux

20x optical zoom lens

Smart Human and Vehicle Detection Alarm

Smart Human Motion Auto Tracking

Day/Night, AWB/MWB,BLC, HLC, 2D/3D-DNR,Shutter, IR-CUT

D-WDR, Mirror, flip, Defogging

Multiply Style OSD Overlay,Motion Detection, Privacy Mask

RTSP and Onvif 17.06 compatible with many third-party NVR

H.264/H.265 dual-stream media server

Easy-to-use P2P Cloud service

Support user authentication, video data encryption

Support Alarm Snapshot to Email and FTP

Multiply WEB browser IE,Firefox,Chrome,Edge,Safari

Free PC Client, Mobile APP remote access

RJ45 100mbps network port, IEEE802.3af 48v PoE

Lightning protection 4000V

Strong water-proof housing IP66

6 PCS Warmlight LEDs, light distance 40-50meters,

8 PCS Array IR LEDs, IR distance 60-80 meters

Support warm light on and colorful imaging when detect human body/vehicle

Build in Mic.

技術仕様
詳細
ビデオ
よくある質問
Model YC-M608FIRC-HS20X
Camera
Image Sensor 1/2.8" Sony CMOS
Effective Pixels 8 megapixels
Electronic Shutter AUTO, 1/10s ~ 1/100000s
Min. Illumination 0.01Lux@F1.2(AGC ON)
Day/Night Auto/Color/(B/W)/Timing
WDR Digital WDR
White Balance Auto/Manual
BLC /HLC Support
DNR 2D/3D DNR
Other Image adjust , Flip
Encode
Video Standard H.264/H.265/Mjpeg
Video Resolution MainStream:20fps@8MP(3840x2160),30fps@6MP(3072x2048)/5MP(2592x1944)/4MP/3MP/1080P/720P,etc.
Sub stream: 720x480/VGA(640x480)/360P/QVGA@30fps,etc.
Third stream: 1080P/720P/CIF @ 10fps
Video Bitrates 512Kbps - 12Mbps, VBR/CBR
Audio Standard G.711-u/G.711-a/AAC
Built-in Mic YES
Smart Detection Smart Human and Vehicle Detection
IR & Warmlight Led
IR Led 8 PCS Array IR LEDs
Warmlight Led 6 PCS Warmlight LEDs
IR Distance 60-80M(IR); 40-50M(Warmlight)
Lens
Focal length 4.7-94mm
IRIS F1.6-3.5
View angle 64 - 2.9 °
Zoom 20x optical zoom
Function
High power PoE
PTZ
Pan/Tilt Range Pan: 0° ~ 360°; Tilt: 0° ~ 90°
Preset Point 128
Control Speed Pan: 0.5° ~40° /s; Tilt: 0.5° ~40° /s
A-B Scanning Support
Auto Cruising Support 8 groups patrol
Power on Action Preset/Scan/Cruise
Power-off Recovery Support
Smart Tracking Human Motion Auto Tracking
Network Services
Protocol HTTP/RTSP/FTP/SMTP/DHCP/NTP/NFS/RTMP, etc.
P2P Yes
Web IE, Firefox, Chrome, Edge, Safari
Media CMS, Android, IOS
ONVIF 17.06 compatible
General
Network Port 1-RJ45, 100Mbps, PoE 48V in
Power Supply 12 VDC ± 10% 2A
Power Consumption < 22 W
Operating Temp. -30℃-(+60)℃, 10%-90%RH

6MP Human body and Vehicle Detection IR& ColorVu POE PTZ IP camera


Human Detection, Vehicle Detection Cross Line, Enter Area, Leave Area, Intrusion, People Flow Counting, Crowd Density Monitoring




  • 1. Can you provide OEM/ODM Service?
    Sure, YCX has over 14-year experience in the security industry, which has the capability of offering excellent ODM/OEM services to customize security products. If you have your own design and have problems for production, welcome here! YCX can offer you stable quality and the best performance security products.
  • 2. How about warranty?
    All YCX products with 24 months warranty since the purchase date. During the warranty period, you can contact our tech support team anytime.
  • 3. How long is the delivery time?
    Usually 15 days after order be confirmed; sample within 7 days. But it will take a little longer if with heavy burden of production task. The final lead time is based on negotiation.Most orders will be shipped via door to door shipping services like DHL, UPS, FEDEX, TNT. While some bulk orders will be shipped via air shipping or sea shipping based on customer's required.Meanwhile, the tracking number will be provided once the goods were sent out.
  • 4. What's the MOQ?
    No MOQ required for sample order, at least one carton per model after sample order.
  • 5. What's your main products?
    YCX mainly provide POE IP security camera system including 3MP/5MP/8MP POE IP Cameras, PTZ cameras , WIFI camera and NVR, also 4 IN 1 cameras and DVRs. YCX developed own professional NVR software GUI 100%, which is stable and unique in the market, it could manage multi-brands IP cameras. Also all YCX IP cameras contain Hik private and standard OVF protocol, which can compatible very well with Hik NVR.
  • 6. Are you a factory or trading company?
    YCX Electronics founded in 2009,which is 100% real factory with covering 5000 square meters plant. with over 14 years experience in manufacture and export security CCTV Camera and recorder products. By using the advance ERP management system, experienced R&amp;D team and strict quality control system,YCX can provide you with high quality security CCTV products.
How dose Network
IP Camera Work?
IP Camera connect directly to the network,with H.265 compressed technology to save the space and bandwidth. It can be remotely viewing in realtime and back up with high quality high definition 4K,5MP,2MP image or video with audio via any PC,Recorder and mobile app to secure people and world safe.
Features of ColorVu IP camera
  • Support multi-channel real-time face image comparison face matching deployment control and calibration linkage.
  • Deep Ai H.265 Smart ip camera with NVR can plug and play and checked by remote CMS and mobile app.
  • AI CMS can unified manage Multiple intelligent NVRs and remotely realtime view the people face.
